Description
Door Guards are designed to protect walls from being damaged by swinging doors.
An integrated rubber stopper acts as a shock absorber, preventing the door from hitting the steel frame. Ideal for commercial and industrial sites, they are suitable for internal and external use and can be installed either individually or in pairs.
Extremely durable, Door Stops are manufactured from galvanised mild steel or stainless steel and available with flange plates for bolting down or extended legs for casting into concrete.
Rubber stopper can be fitted in one of six positions.
Custom colour coating is available at an additional cost, on request (RAL or BS number required).
Product Details
- 2.5mm wall thickness (tube)
- Round flange plate – 120mm x 5mm
- 900mm x 700mm (height x width)
- 6 bolts required per door guard (bolt down)
- Concrete in 300mm (below ground)
- 50mm x 5mm tapping rail
138206005 – Finish: Galvanised, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Concrete In (Approx 300mm)
138206001 – Finish: Galvanised, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Bolt Down – Excludes Fixing Bolts
138206015 – Finish: Galvanised, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Concrete In (Approx 300mm)
138206011 – Finish: Galvanised, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Concrete In (Approx 300mm)
138206025 – Finish: Galvanised, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Concrete In (Approx 300mm)
138206025 – Finish: Galvanised, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Bolt Down – Excludes Fixing Bolts
138206009 – Finish: Stainless Steel Grade 304, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Concrete In (Approx 300mm)
138206004 – Finish: Stainless Steel Grade 304, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Bolt Down – Excludes Fixing Bolts
138206019 – Finish: Stainless Steel Grade 304, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Concrete In (Approx 300mm)
138206014 – Finish: Stainless Steel Grade 304, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Concrete In (Approx 300mm)
138206029 – Finish: Stainless Steel Grade 304, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Concrete In (Approx 300mm)
138206024 – Finish: Stainless Steel Grade 304, 48mm Diameter. Width: 700mm, Height Above Ground: 900mm, Fixing: Bolt Down – Excludes Fixing Bolts
Installation & Use
- Bolt down to a suitable concrete surface.
- Telescopic, removable and concrete in are supplied with welded fixing spikes to ensure firm ground anchorage into concrete.
- Telescopic, removable and concrete in require a suitable excavated hole for installing into concrete.
- Products are guaranteed for 12 months (if installed and used correctly)
