Description
Ideal Safety Warehouse Steps for buildings with limited entrance space, tight doorways / halls, low hanging lights and beams which make access restrictive.
These steps are based on the same design as our Industrial Range but delivered ‘knocked down’ for assembly on-site.
The mobile steps come fully welded from heavy duty tube and box section and they are ready to use! Includes a central brake for safe working and a choice of PVC covered, rubber covered or punched metal treads, as well as 6 different colour options.
- HEAVY duty
- SWL 300kg
- Fully welded and ready to use
- Central braking system
- Choice of PVC covered, rubber covered or punched metal treads
- Choice of blue, red, yellow, green, grey or orange as standard
- Made in the UK
- Specification sheet
| Product Code | Treads | Working Platform Height | Working Height |
Overall Height | Overall Width | Overall Length | Packed Dims H x W x L |
Weight | Brake Type |
|---|---|---|---|---|---|---|---|---|---|
| KK05 | 5 | 1250 | 2250 – 3000 | 2250 | 850 | 1270 | 900 x 850 x 2450 | 55 | Central brake |
| KK06 | 6 | 1500 | 2500 – 3250 | 2500 | 850 | 1360 | 900 x 850 x 2700 | 62 | Central brake |
| KK07 | 7 | 1750 | 2750 – 3500 | 2750 | 850 | 1450 | 900 x 850 x 3000 | 70 | Central brake |
| KK08 | 8 | 2000 | 3000 – 3750 | 3000 | 850 | 1575 | 900 x 850 x 3400 | 78 | Central brake |
| KK09 | 9 | 2250 | 3250 – 4000 | 3250 | 850 | 1730 | 900 x 850 x 3600 | 90 | Central brake |
| KK10 | 10 | 2500 | 3500 – 4250 | 3500 | 1000 | 1905 | 900 x 1000 x 4000 | 98 | Central brake |
| KK11 | 11 | 2750 | 3750 – 4500 | 3750 | 1000 | 2070 | 900 x 1000 x 4400 | 105 | Central brake |
| KK12 | 12 | 3000 | 4000 – 4750 | 4000 | 1000 | 2230 | 900 x 1000 x 4700 | 116 | Central brake |
| KK13 | 13 | 3250 | 4250 – 5000 | 4250 | 1230 | 2470 | 900 x 1230 x 5000 | 125 | Central brake |
| KK14 | 14 | 3500 | 4500 – 5250 | 4500 | 1230 | 2630 | 900 x 1230 x 5200 | 130 | Central brake |
| KK15 | 15 | 3750 | 4750 – 5500 | 4750 | 1320 | 2795 | 900 x 1320 x 5500 | 138 | Central brake |
WORKING HEIGHT: Is a general ‘guide’ taken between waist height and just above the shoulders of the average person (approx. 750mm range).
